Safety light sensor EFP0820NLD2-12-NS

Technical Specifications

• Reference Standards
  EN 61496-1 (Type 4 ESPE)
  EN 61496-2 (Type 4 ESPE)
  EN ISO 13849-1 (Type 4, PL e)

• Safety Level: Type 4

• Supply Voltage: DC 24V ±20%

• Power Consumption: < 5W

• Beam Spacing: 10 mm, 20 mm

• Resolution: 15 mm, 25 mm

• Number of Beams:

  • 10 mm spacing: 16 … 160 beams

  • 20 mm spacing: 8 … 80 beams

• Protective Height: (N – 1) × beam spacing (N = number of beams)

• Wavelength: 940 nm

• Response Time: (N × 0.1 ms) + 0.4 ms (N = number of beams)

• Output Type (OSSD):

  • PNP/NPN semiconductor output

  • Current < 200 mA

  • Residual voltage ≤ 1V

  • Leakage current ≤ 1 mA
    (Excluding voltage drop due to cable extension)

• Protective Circuits:

  • Overvoltage protection

  • Reverse polarity protection

  • Overcurrent protection

• Sensing Distance: 0.1 – 2 m, 0.1 – 5 m
  (Note: For strong light reflection, please confirm before use)

• Anti-optical Interference: 10000 Lux

• Sensing Method: Through-beam type

• Synchronization: Wire synchronization

• Enclosure Material: Aluminum alloy

• Enclosure Rating: IP65

• Housing Cross-section: 30 × 28 mm

• Vibration Resistance: 10 Hz – 55 Hz, amplitude 0.35 ± 0.05 mm, 20 times in X, Y, Z directions

• Operating Temperature: -10°C ~ +55°C (no freezing)

• Storage Temperature: -30°C ~ +70°C (no freezing)

• Ambient Operating Humidity: Max. 85% RH at 20°C
